Ryobi Benzin RHT2660R Listas de piezas de repuesto y dibujos

RHT2660R Benzin

Ryobi Heckenscheren Benzin RHT2660R Seite 1
PosNúmero de artículoDescripción
002 5131011519SCREW RHT2660DA
003 5131035193HANDLE
003.2 5131009426VIBRATION RUBBER RHT2660DA
003.3 5131026858BUSHING
005 5131026858BUSHING
006 1000063920PART NOT DEATAILED
007 5131035194HOUSING
007.1 5131008607CLUTCH DRUM RHT2660DA
007.2 5131011006BEARING RHT2660DA
007.3 5131011780C RING RHT2660DA
007.5 5131010998WASHER RHT2660DA
007.6 5131011577SCREW RHT2660DA
007.8 5131013254FELT SEAL RHT2660DA
014 5131013254FELT SEAL RHT2660DA
015 5131035200WASHER
016 5131008625GEAR ASSY RHT2660DA
017 5131013253GASKET RHT2660DA
018 5131008564GEAR BOX COVER RHT2660DA
018.1 5131010980BUSHING RHT2660DA
018.2 5131010980BUSHING RHT2660DA
020 5131035201HOUSING
021 5131011544SCREW RHT2660DA
022 5131011544SCREW RHT2660DA
024 5131011799WASHER RHT2660DA
025 5131016461CONNECTING ROD
026 5131035202SCREW
028 5131035203HANDLE HALF R
028.2 5131011814NUT HHT2655
030 5131011822ITEM DISCONTINUED TO CANCEL
031 5131011821SPRING RHT2660DA
032 5131029195TRIGGER
033 5131011817ITEM DISCONTINUED TO CANCEL
034 5131029196LOCK
035 5131001920LOCK
036 1000063920PART NOT DEATAILED
037 5131011547ITEM DISCONTINUED TO CANCEL
038 5131011474SCREW HLT26CD
042 5131035204BLADE
042.4 5131035208SPACER
044 5131035212SCABBARDS
047 5131035213RUBBER
048 5131035214NUT
049 5131035215WASHER
050 5131035216RETAINING RING
055 5131035220WASHER
